The U200 V2 is a high-performance Brushless DC (BLDC) motor speed controller designed for 5 to 14S LiPo batteries. With a continuous current rating of 200A and a peak current of 240A, it’s optimized for demanding applications like powered paragliders. Weighing approximately 320g and featuring robust 8 AWG power and motor lines, this Brushless DC Motor Automatic Electric Speed Controller ensures excellent efficiency under good cooling conditions.

Features:

1. Protective Functions: Short circuit, stall, voltage, temperature, and throttle loss protections enhance safety.
2. Throttle Range: Adjustable throttle pulse width (1050us-1940us) compatible with 3.3V/5V input signals.
3. Communication: RS-485 interface for seamless integration with flight controllers.
4. Environmental Rating: IP67-rated for protection against dust and water.
5. Size: 117.5 x 56.3 x 42.8 mm
6. Weight: 320g (excluding wires)
7. Operating Temperature: -25 to 60°C
8. Current Limiting: 200A
9. Recommended Battery: 12S
10. Signal Frequency: 50-500Hz

Package Includes:

1× XC ESC – 12s 200A 48V 13HP Powered Paraglider Brushless DC Motor Automatic Electric Speed Controller

Specification:-
